2.Shipping to Other countries,it is two years update. After getting the device,please send me the SN number to active the 2 years update.

Warm Reminder for North America Region

To do key programmer,you need BEST key programming tools - Autel IM608 II , Updated Version of IM608PRO

Autel IM608 II (IM608 PRO II)is the most advanced key Pro/gramming tool that combines the powerful IMMO and Pro/gramming functions with OE-level diagnostics and advanced service functions in one tablet. It can read the immobilizer pins and password directly from the vehicle and store this information to use later when learning the newly Pro/grammed keys to the vehicle.

Reasons To Buy IM608 II

√IM608 II = IM608 PRO II = IM608S II

√Hardware Configuration Runs 5x Faster Diagnostic Speed

√Smart Mode and Expert Mode Solution In One Tool

√ ECU Coding & Online Coding & Offline Coding

√IMMO ECU Online Programming for BMW & Benz

√40+ Maintenance Functions + VAG Guided Functions

√Bi-directional Control (Active Test) + OE-level All System Diagnostics

√CAN FD & DoIP, D-PDU, RP1210

√Remote Desk + Cloud Data Management + Pre & Post Scan

√Auto VIN + Scan VIN/License

Newest Function Release

1. VIN/Odometer Check
• Adds "VIN/Odometer Check" feature, which supports reading the mileage and Vehicle Identification Number (VIN) values stored in various control units of the vehicle.

• By comparing the values, it serves as reference information for the maintenance history of the vehicle module.

• Supported Manufacturers：Chrysler, Dodge, JEEP, Porsche, Hyundai, Kia, Genesis, Fiat, Alfa, Abarth, Lancia, VW, Audi, Bentley, Lamborghini, Seat, Skoda, Nissan, Infiniti, NissanGTR, Toyota, Scion, Lexus, Subaru, Suzuki, Ford, Mazda, Peugeot, Citroen, DS, LandRover, Jaguar, GM, Chevrolet, BMW, Mini, Renault, Dacia, Samsung, Volvo, Polestar, Benz, Maybach…

2.Live data fusion
•Adds “Live Data Fusion" feature, which enables the integration of live data from different systems onto a single interface, facilitating dynamic display.

•Widely applied in maintenance scenarios requiring simultaneous monitoring of live data from multiple systems, such as addressing U-code, ABS malfunctions, aftertreatment, and more.

•Supported Manufacturers: Chrysler, Dodge, JEEP, Hyundai, Kia, Genesis, VW, Audi, Bentley, Lamborghini, Seat, Skoda, Toyota, Scion, Lexus, Subaru, Suzuki, Ford, Peugeot, Citroen, DS, LandRover, Jaguar, Renault, Dacia, Samsung…

What's The Difference Between IM608 II and IM608 PRO?

1.Improved Hardware Configuration: Updating from IM508/IM608/IM608 PRO, 2023 Autel IM608 II PRO key programmer improves 5x faster diagnostic speed, expands its memory from 64GB to 128GB, updates its operating system from Android 4.4.4 to Android 10.0, enhances its processor from 4-core to 8-core, etc.

2.Auto VIN & Scan VIN/License: Autel IM608II PRO diagnostic tool can automatically recognize vehicle information as soon as it is connected. You can also scan the VIN code or license to perform a quick scanning and match the right diagnostic process to easily pinpoint the vehicle trouble codes.

3.Wide Protocols: Compatible with CAN FD & DoIP, D-PDU, RP1210, J2534. Autel IM608II PRO car scanner empowers mechanics to negotiate wider vehicle coverage and performs advanced programming for IMMO ECU.

4.Broader Vehicle Coverage:

Autel IM608 II PRO key programmer immobilizer works on global 80+ American, European, Asian vehicle makes and 10000+ models. Thanks to the timely updating, the compatibility covers up to 2021, 2022, and some up to 2023 newer models.

Detailed Information of IM608II

■ Languages

English, Spanish, French, German, Polish, Italian, Japanese, Korean, Dutch, Portuguese,Swedish, Russia,Arabic,Turkish,Thailand,Vietnam

After getting the product,please contact with us to active the language.

■ IMMO & Key Programming Expert

The XP400 Pro has been extended IMMO functionalities on BMW, BENZ and Audi etc., designed to work with IM508, IM608, IM608 Pro to perform various IMMO Key Pro/grammings, key chip Pro/gramming functions, MCU writing and reading,etc. Auto Detect Make, Model, Year, System. Read PIN (All Key Lost), Key Learning, IMMO ECU Reset/Adaption, IMMO ECU Refresh/Coding, Remote Learning

For AU-DI Q5/ A4/A5 2015-2017 Key Learning
For VW MQB Key Learning
For BM-W FEM/ BDC Key Learning and Adaption
For BM-W CAS4 Key Learning and Adaption
For Mercedes Key Learning
For 2015-2018 Land Ro-ver & Jag-uar write key via dump
For Volvo Smart Key Learning/ knob-style smart key, etc.

1) XP400Pro Adds Support for Following Chips:

EEPROM-->>AMD-->>AM29FXXX series chip
EEPROM-->> FUJITSU-->> MB29FXXX series chip
EEPROM-->> ST-->> M29FXXX series chip
Engine control module-->> ST-->> M29FXXX series chip
IMMO-->> BENZ-->> ESL_W209_W906 (Motorola) read/write/erase function
IMMO-->> BMW-->>EWS3 module read/write function
REMOTE_RENEW(renew key)-->> NEC-->> V51 and V5 chip read/write/erase

2) XP400 Pro Adds Support for Following Adaptor Board:

APB113 PCF79XXadaptor board
APB114 EWS3 adaptor board
APB115 NEC Adapter board
APB118 NEC ELV adaptor board
APB119 TB28FXXXadaptor board
APB120 TMS370adaptor board
APB121 AM29FXXX Adapter board
APB122 AM29FXXX adaptor board1
APB123 AM29FXXX adaptor board2
APB126 M35080/D80 adaptor board
APB127 MC68HC0(7)05BXX adaptor board
APB128 MC68HC05X32 adaptor board

■ ECU Coding

The Coding function is used to re-flash the vehicle control modules, it allows you to update the computer software on the vehicle to the latest version, as well as to reprogram adaptive data for certain components after making repairs or replacements, providing ways for the issues of Drivability, Fuel Efficiency, Power Loss, Fault Codes, Durability of Mechanical Parts.

■ J2534 Programmer

It is an SAE J2534-1 & -2 compliant PassThru reprogramming interface device, with stable, fast processing performance and strong compatibility. Using the updated OEM software, it is capable of replacing the existing software/firmware in the ECUs, programming new ECUs, and fixing software-controlled drivability issues and emission issues.

Note: Need OEM software.

■ Active Test

The process of sending and retrieving information from a vehicle control module with a device is known as Actuation test or bi-directional control. The main aim of the actuation test function is to request the control module to perform a specific function including system tests, actuator tests, functional tests, inspection tests, reprogramming or reinitialization, thus saving diagnostic time.

Eg: You connect a fuel pressure gauge, cycled the key and cranked the engine but you couldn’t figure out anything regarding the fuel pressure. With the actuation test function of this diagnostic tool, you can send a fuel pump command on instruction and see the proper fuel pressure, figuring out if there is a problem with the fuel pump circuit or pump.

Work With IMKPA/APB112/G-box2

■ IMKPA

IMKPA is a key programming kit (including 12 adapters for the XP400 PRO). When working with the XP400Pro Key & Chip Programmer, it enables mechanics to operate Read/Write/Erase for Mercedes Benz ESL_W209 / W906 Data, Mercedes Benz NEC Key Learning, BMW EWS3 Key Learning and VW/Audi/BMW/Benz Key Unlock.

■ APB112

Autel APB112 smart key simulator is designed to work with Autel IMMO key programming tool MaxiIM IM608 PRO, which can be used to collect the data sent from the ignition coil, identify ignition coil troubles, collect vehicle key chip data (Hyundai 46), simulate vehicle key chip (ex- 4D chip), calculate smart key password, etc.

■ G-BOX3

The Autel G-BOX2 is an adapter (compatible with Autel IM608 PRO) used to program keys for Mercedes DAS3 CAN EIS/EXS (All Keys Lost) and DME/DDE ISN Reading &Writing for BMW. With this G-BOX2 tool, All Keys Lost password calculations improve 4x to 8x faster speed and greatly simplify the operation steps.

■ All-system Diagnostic

Simply accessing the diagnostic modes via AutoVin or Control Unit, and you're able to perform diagnosis over all the systems on the vehicle's ECU in order to locate fault systems and retrieve DTCs.
ECU Information -provides the retrieved ECU information in detail.

Read Codes -displays detailed information of DTC records retrieved from the vehicle control module.

Erase Codes -erases DTC records and other data from the ECM.
Live Data -retrieves and displays live data and parameters from the vehicle's ECU.

■ 40+ Service Functions

40+Service Functions for various scheduled service and maintenance performances including : Oil Reset, EPB, TPMS, BMS, Brake Bleed, DPF, Immo Keys, Injector, SAS, Suspension, Throttle, WIN DR ROOF, Seats, Lang Change, Headlamp, CHG Tire Size, TEC Learn, ABS/SRS, Cylinder, Turbocharging, Limit, Clutch, Trans Adaption, Airbag Reset.


Oil Reset Service: Allows you to perform reset for the Engine Oil Life system, which calculates an optimal oil life change interval depend on the vehicle driving conditions and climate.

EPB Service: Helps maintain the electronic braking system safely and effectively, deactivating and activating the brake control system, assisting with brake fluid control, opening and closing brake pads, and setting brakes after disc or pad replacement, etc.

SAS Service: Allows you to perform calibration for the Steering Angle Sensor, which permanently stores the current steering wheel position as the straight-ahead position in the steering angle sensor EEPROM.

DPF Service: Allows you to carry out numerous functions to the Diesel Particulate Filter system.

TPMS Service: Allows you to quickly look up the tire sensor IDs from the vehicle's ECU, as well as to perform TPMS programming and reset procedures after tire sensors are replaced.

IMMO Service: Programs a new anti-theft key, and performs key matching when the ignition switch, the combined instrument panel, ECU, BCM, or the remote control battery is replaced.

And Many More...

■ Wide Vehicle Coverage- 10,000+ models

For Audi: A1, A3, A4, A5, A6, RS4, B6, B7, RS5, RS6, A4 Allroad, A8, S8, Q3, RSQ3, Q5, Q7, R8, TT
For Seat: Alhambra, Altea, Altea, Cordoba, CupraLeon, Exeo, Ibiza, Leon, Mii, Toledo
For Skoda: Citigo, Fabia, Kamiq, Karoq, Octavia, Rapid, Roomster, Superb, Yeti
For VW: Amarok, Arteon, Atlas, Beetle, Bora, BoraGli, Caddy, Crafter, EOS, Fox Africa, Fox EU, Fox, GTI, Gol County, Gol(5U), Gol(5W), Golf PLUS, Golf/Rabbit(1K), Golf6 ESTATE, Jetta, Parati, Passat, Phaeton, Polo, Scirocco, Sharan, Suran, T-Roc, Tiguan, Touareg, Touran, Transporter5/Multivan, up, UP!/cross UP!
For Fiat: 500, 500L, 500X prox, Albea, Boxer, Daily, Doblo, Doblo New, Ducato, Egea, Fiorino, Freemont, Idea, Grande punto, Jumper, Linea, Marea, Nemo, Ottimo, Palio, Palio RST, Panda, Perla, Promaster, Punto, Sinea, Stilo, Viaggio

Don't support the local vehicleAustralian car: Fordau, Holden
Malaysian car: Perodua,proton
Brazil, Latin America, South America: Fiat Brazil, Gm Brazil

If you need to add the following car software,please contact with us.

■ Specifications

VCI:JVCI+
Programmer: XP400 Pro
Hardware CPU:
4x 2.2GHZ (A73)
4x 1.8GHZ (A53)
OS: Android 10.0
Memory:4G RAM, 128G Flash
Display:10.1 inch
Resolution: 1920*1200
Battery: 15000mAh
VCI Connection: BT5.0/USB
DoIP: Yes, no need converter
CAN FD: Yes, no need converter
Diagnostic Function: Comprehensive diagnostic
Coding: Yes
Programming: BMW, Mercedes online programming
Immobilizer Function: Immo programming Full immo function
Programmer: Read/Write EEPROM, MCU
Key Tool Function: Yes
Remote Expert: Yes
